UPS5000-E-(50 kVA-300 kVA)
User Manual (50 kVA Power Modules)
Copyright © Huawei Technologies Co., Ltd.
The number and colors of signal cables are for reference only.
----End
3.2.8 Routing Cables (UPS5000-E-300K-SM)
Context
Route cables for the UPS from inside out.
Procedure
Step 1 Open the front door, and remove the cover from the power distribution subrack, as shown in
Figure 3-71. Figure 3-72 shows the positions of copper bars.
Figure 3-71 Removing the cover
