Chapter 9 Troubleshooting
265
Alarm
Code
Alarm
Level
Alarm Name Cause/Treatment
0CF
Operation
release
I/O 24V power supply error Cause : 24V power supply for PIO is not connected. The
voltage is extremely low.
Treatment : Check the connection and voltage.
0D2 Motor power source
voltage excessive
Cause : A breakdown of the part inside the controller is
considered.
Treatment : If this error occurs frequently, the controller may be
faulty at high probability. Please contact IAI.
0D3
Cold start
Motor power supply
voltage low
Cause : 1) If the power source is shut off out of the
controller, servo-on command was made during
the power is shut.
2) There is a concern of a malfunction of the
controller internal components.
Treatment : 1) Check the controller external circuit.
2) If this error occurs often, there is a concern of a
controller malfunction. Please contact us.
0D6
Operation
release
FAN error detection Cause : The number of the FAN revolution has dropped to
the alarm level.
Treatment : Check if the FAN is connected properly, and if this
alarm cannot be solved, degradation or malfunction
of the FAN can be considered. Replace the FAN.
0D7 Cold start Belt breaking sensor
detected
Cause : The belt of the ultra-high thrust RCS2-RA13R is
broken.
Treatment : Belt must be replaced. Please contact IAI.
0D8 Deviation overflow Cause : This alarm indicates that the position deviation
counter has overflowed.
1) The speed dropped or the actuator stopped due
to the effect of external force or overload.
2) The excited-phase detection operation following
the power-on is unstable.
3) The power supply voltage dropped.
4) Servo gain number is too small
5) There is a concern of malfunction in controller
component (IPM).
Treatment : 1) This error occurs when the actuator cannot be
operated as it is commanded. Check the load
conditions such as if the work is touching to the
surrounding object, or brake is properly
released, and remove the cause.
2) Overload can be concerned. Revise the
transportable weight and redo the home-return
operation.
3) Check for the source voltage.
5) Replace the controller (PC board).
0D9 Software stroke limit
exceeded
Cause : 1)
The current position of the actuator has
exceeded the software stroke limit.
2) The rotary mode has changed from the index to
the normal mode on the rotary actuator.
Treatment : 1)
Put the actuator back into the range of the
software stroke limit.
2) Revise the values in Parameter No. 3 and
4.
0DA
Operation
release
Feed back pulse error Cause : Feedback pulse data cannot be output within the
cycle.
Treatment : Take proper measures against noise.
To Next Page
