Chapter 1 Specications Check
41
SCON-CAL/CGAL
10 mm
or more
10 mm
or more
10 mm
or more
1 mm
or more
1 mm
or more
50 mm
or more
50 mm
or more
150 mm or more
Air flow
Apply screws sized M4 × 10mm when attaching the product with screws.
Caution for DIN Rail Type
Insertion and removal of a connector is assumed for the external force applied to the product.
There is a concern of damage if force exceeding it is applied on the product. Do not attempt to apply
force to any area except for the front of the product.
* When removing a connector with locking feature such as an encoder connector or PIO connector,
make sure to release the lock before pulling it off.
