Chapter 2 Wiring
81
SCON-CAL/CGAL
Pin No.
Signal Name
Contents Applicable cable diameter
1 NC
2 NC
3 NC
4 NC
5 NC
6 NC
Unconnected
7 SRD6+
Serial Encoder
Communication +
8 SRD-
Serial Encoder
Communication -
9 NC
10 NC
11 NC
Unconnected
12 24VOUT Sensor 24V Power Supply +
13 0V Sensor 24V Power Supply -
14 BAT+ ABS Battery Power Supply +
15 BAT- ABS Battery Power Supply -
16 VCC Encoder Power Supply +
17 GND Encoder Power Supply -
18 NC
19 NC
Unconnected
20 BK- Brake Power Supply-
21 BK+ Brake Power Supply+
22 NC Unconnected
23 RSV Sensor Input (Reserve)
24 OT Sensor Input (Over Travel)
25 CREEP Sensor Input (Creep sensor)
26 LS Sensor Input (limit switch)
Cable dedicated for IAI
encoders
To Next Page
