IBM RS/6000 7025 F50 Series User Manual

FRU Name
AIX
Location Code
Physical
Location Code
Physical
Connection
Logical
Identification
SCSI Backplane
D
When
connected to
PCI adapter in
slot P2-In
AB-CD-00-15, 0
Where AB-CD
identifies the
adapter's slot
P2-In-Z1-B2 Bus ID 15
DASD in Bays
D1 through D6
When
connected to
SCSI Port 2
(P2/Z2)
30-58-00-G, 0
Where G
identifies
Secondary SCSI
Bus ID 8
through 13
P2-Z2-B2.1
through B2.6
Backplane
connector J6
through J11
Slots A through
F
Secondary SCSI
Bus ID 8
through 13
DASD in Bays
D1 through D6
When
connected to
PCI adapter in
slot P2-In
AB-CD-00-G, 0
Where AB-CD
identifies the
adapter's slot
and G identifies
the SCSI Bus ID
8 through 13
P2-In-Z1-B2.1
through B2.6
Backplane
connector J6
through J11
Slots A through
F
Bus ID 8
through 13
SCSI Backplane
E
When
connected to
PCI adapter in
slot P2-In
AB-CD-00-15, 0
Where AB-CD
identifies the
adapter's slot
P2-In-Z1-B2 Bus ID 15
DASD in Bays
E1 through E6
When
connected to
PCI adapter in
slot P2-In
AB-CD-00-G, 0
Where AB-CD
identifies the
adapter's slot
and G identifies
the SCSI Bus ID
8 through 13
P2-In-Z1-B2.1
through B2.6
Backplane
connector J6
through J11
Slots A through
F
Bus ID 8
through 13
Fans
Fan 1 F1 Fan connector
J12 at I/O Board
Fan 2 F2 Fan connector
J17 at I/O Board
Fan 3 F3 Fan connector
J15 at I/O Board
Fan 4 F4 Fan connector
J19 at I/O Board
Fan 1
Connector
P2/F2 Fan connector
J12 at I/O Board
Fan 2
Connector
P2/F2 Fan connector
J17 at I/O Board
Chapter 3. Error Code to FRU Index 3-53
