7. IPL Boot Code
The system firmware attempts to boot from the devices listed in the Boot
List.
LCD Code range is E1XX.
8. Boot Image Execution
Once a boot image is located on a device in the Boot List, the system
firmware code hands off control to the AIX Boot code.
– LCD Code E105 for Normal Boot or
– E15B for Service Mode Boot.
The AIX Boot code indicates LCD progress codes in the range from 05XX to
09XX.
9. AIX Boot Complete
The AIX login prompt appears on the main console.
Specifications
The mechanical packaging, cooling, power supply, and environmental requirements
for the server is shown in the following:
Dimensions
Height - 620 mm (24.3 inches)
Depth - 695 mm (27.3 inches)
Width - 245 mm (9.6 inches)
Weight
Configuration dependent
Operating Environment - Class B
Temperature - 16° to 32°C (60° to 90°F)
Humidity - 8% to 80% noncondensing
Maximum Altitude - 2135 m (7000 feet)
1-10 Service Guide
