AIX Location Codes
The basic formats of the AIX location codes are:
For non-SCSI devices/drives
AB-CD-EF-GH
For SCSI devices/drives
AB-CD-EF-G,H
FRU Name
AIX
Location Code
Physical
Location Code
Physical
Connection
Logical
Identification
Fan 3
Connector
P2/X3 Fan connector
J15 at I/O Board
Fan 4
Connector
P2/X4 Fan connector
J19 at I/O Board
Service Processor
Service
Processor
P2-X1 I/O board
Connector J10
Operator Panel
Operator Panel L1 I/O board
Connector J22A
Operator Panel
Connector
P2/L1 I/O board
Connector J22A
Power Supply
Power Supply V1 I2C Ad 92, Ch2;
RTAS=9002-0
Note: The SCSI bus ID's are the recommended values. Features installed at the manufacturing site
will correspond to these IDs. Field installations may not comply with these recommendations.
3-54 Service Guide
