Power Supply
DANGER
Do not attempt to open the covers of the power supply. Power supplies
are not serviceable and are to be replaced as a unit.
Removal
1. If you have not already done so, remove the covers as described in “Covers” on
page 6-3.
2. Disconnect the two cables from I/O Planar connectors P1, and P2.
3. Disconnect the four cables from the System Card connectors J1, J2 J3, and J4.
4. Disconnect the cables from the Processor Cards.
Chapter 6. Removal and Replacement Procedures 6-15
