Step 1540-17
The Adapter or device is probably defective.
If the supplemental media is for an adapter replace the FRUs in the following order:
1. Adapter.
2. The planar the adapter is plugged into.
If the supplemental media is for a device replace the FRUs in the following order:
1. Device and any associated cables.
2. The adapter the device is attached to.
Repeat this step until the defective FRU is identified or all the FRUs have been
exchanged.
If the symptom did not change and all the FRUs have been exchanged, call your
service support person for assistance.
If the symptom has changed, check for loose cards, cables, and obvious problems.
If you do not find a problem, return to “Step 1540-1” on page 2-18 on this MAP and
follow the instructions for the new symptom.
Go to "MAP 410: Repair Checkout" in the
IBM RS/6000 Diagnostic Information for
Multiple Bus Systems
.
2-34 Service Guide
