Index Part Number Units Per Description
1x 93H8544 1 Chassis assembly (includes covers and
side door)
2 73H0898 1 EMC clip
3 06H7082 1 Display panel
4 93H1816 1 Cable (Display)
5 93H2922 1 Operator panel control assembly
6 07L6594 1 I/O Board
7 06H7697 13 Standoff
8 33F8354 1 Battery
9 73H3520 1 CPU Lever
73H3525 1 Lever (front)
73H3529 1 Lever (rear)
10 93H3960 1 Brace
73H3531 1 Card Guide
11 93H6280 1 Cable (EPOW)
12 73H3577 1 Fan (#1)
40H1424 1 Fan (#3)
40H1433 2 Fan (#2 and #4)
13 93H4214 1 Service processor
14 93H2641 1 or 2 Memory Card
15 93H4700 Up to 8 pair 32MB memory module
93H4702 Up to 8 pair 128MB memory module
16 See note Up to 9 Adapter card
17 93H2679 1 or 2 166 MHz CPU card (1 way)
73H4768 1 or 2 166 MHz CPU card (2 way)
93H9018 1 or 2 332 MHz CPU card (1 way)
93H8945 1 or 2 332 MHz CPU card (2 way)
18 93H3144 1 EMC gasket (I/O connectors)
19 93H3145 1 EMC gasket (Ext. SCSI connector)
20 93H2166 1 SCSI Backplane (Hot swap)
93H6321 1 SSA Backplane (Hot swap)
21x 93H8797 1 Door assembly, right side
22 93H9789 1 I/O Planar cover
23 93H9789 1 Power supply
24 93H4529 1 Adapter card bracket
25 CD ROM 1 See note
26 11H8156 1 Pedestal and wheel
27 73H1881 1 Front cover (IBM)
73H1897 1 Front cover (OEM)
28 93H4297 1 Logo
29 See Note 1 Diskette drive
30 06H2792 1 Plate assembly
31 73H0870 1 Bezel (Operator panel)
32 See note Up to 2 Media device
33 40H3142 1 Bracket (Display panel)
34 See note Up to 18 Disk drive
35 See note Up to 18 Disk drive carrier assembly
36 93H60109 1 Serial/Parallel Card and Cables
37 73H1925 1 System Board
Chapter 7. Parts Information 7-3
