Table 3-1 (Page 23 of 24). Firmware Error Codes.
Error Code Description Action / Possible Failing FRU
4B2xxx43 Service Processor reports JTAG fail 1. Service Processor is the least likely
failure, but it is the tester in this
case. Replace the Service
Processor to assure true failure
indication. If the failure disappears,
the Service Processor was bad.
Otherwise, reinstall the old Service
Processor.
2. Remove the CPU(s) and the
System Board. If the failure
returns, replace the I/O planar.
(See notes on 3-1.) Otherwise,
continue.
3. Install the System Board WITHOUT
the CPU(s). If the failure returns,
replace the System Board.
Otherwise, continue.
4. Install the CPU Card in slot 1. If
the failure returns, replace that
CPU Card. Otherwise, continue.
5. Install the CPU Card in slot 2 (if
there was one). If the failure
returns, replace that CPU Card.
Otherwise, continue.
6. If the failure is still absent, the
problem was a bad connection,
and you have reseated the
possible connections.
4BA00000 The system support controller detects
the service processor, but cannot
establish communication. The system
halts.
1. Replace the service processor.
2. Replace the I/O board.
4BA00001 The system support controller cannot
detect the service processor.
Replace the service processor.
D 4BA00830D Boot failure.D See “E1xx Code Boot Problems” on
D page 3-44.
4BA80013 NVRAM Refer to map 1540 in the system unit's
Service Guide.
4BA10001 SSC sram fail Refer to map 1540 in the system unit's
Service Guide.
4BA10002 SSC sram fail Refer to map 1540 in the system unit's
Service Guide.
4BA10003 Service Processor Fail. Replace Service Processor.
3-24 Service Guide
