Scenario 2: Switch with Only Active Supervisor Module
About this task
To perform a nondisruptive migration from a Supervisor-1 Module to a Supervisor-4 Module in a switch
that has only the active supervisor module installed and there is no standby supervisor module, or the
standby module is not in the HA-standby state, follow these steps:
Procedure
1. Use the show module command to view the active and standby supervisor modules.
Note: In the following system message, Supervisor-1 Module is listed as Supervisor-4 Module.
switch# show module
Mod Ports Module-Type Mode Status
--- ----- ----------------------------------- ------------------
----------
1 48 1/10 Gbps Ethernet Module DS-X9848-480K9 ok
2 48 4/8/10/16 Gbps Advanced FC Module DS-X9448-768K9 ok
3 24 40 Gbps FCoE Module DS-X9824-960K9 ok
4 48 4/8/16/32 Gbps Advanced FC Module DS-X9648-1536K9 ok
5 0 Supervisor-4 Module DS-X97-SF1-K9 active *
7 34 1/10/40G IPS, 4/8/10/16G FC Module DS-X9334-K9 ok
8 48 4/8/16/32 Gbps Advanced FC Module DS-X9648-1536K9 ok
10 48 4/8/10/16 Gbps Advanced FC Module DS-X9448-768K9 ok
Mod Sw Hw
--- --------- ------
1 8.4(1) 1.1
2 8.4(1) 1.3
3 8.4(1) 1.0
4 8.4(1) 1.0
5 8.4(1) 1.3
6 8.4(1) 1.1
7 8.4(1) 1.0
8 8.4(1) 1.0
10 8.4(1) 1.1
Mod MAC-Address(es) Serial-Num
--- -------------------------------------- ----------
1 84-78-ac-1b-3d-58 to 84-78-ac-1b-3d-8b JAF1718AAAD
2 f4-cf-e2-7c-cd-30 to f4-cf-e2-7c-cd-33 JAE1847038X
3 04-6c-9d-32-36-aa to 04-6c-9d-32-37-1b JAE19330ASN
4 00-76-86-bf-58-23 to 00-76-86-bf-58-57 JAE203901ZG
5 9c-57-ad-fd-0d-cb to 9c-57-ad-fd-0d-dd JAE194005JC
6 e8-ed-f3-e5-9a-4d to e8-ed-f3-e5-9a-5f JAE17440HVB
7 00-da-55-a2-25-00 to 00-da-55-a2-25-0f JAE195004XM
8 74-86-0b-33-c6-70 to 74-86-0b-33-c6-a4 JAE213101Q3
10 3c-0e-23-c5-53-d0 to 3c-0e-23-c5-53-d3 JAE180605X3
Mod Online Diag Status
--- ------------------
1 Pass
2 Pass
3 Pass
4 Pass
5 Pass
6 Pass
7 Pass
8 Pass
10 Pass
Chapter 3. Installing the IBM c-type SAN Device93
