IBM Storwize V7000 - Page 134

CAUTION: To avoid personal injury, before lifting this unit, remove all appropriate subassemblies
per instructions to reduce the system weight. (C012)
Notes:
• Perform the following procedure only if directed to do so by IBM Remote Technical support or by a x
procedure in the management GUI.
• An enclosure can have FRU P/N 01LJ112 or FRU P/N 01LJ607. When needed, an enclosure with FRU
P/N 01LJ607 is used to replace FRU P/N 01LJ112.
This task assumes that the following conditions are met:
• All power cables were removed from the enclosure, as described in “Powering off the expansion
enclosure: 2076-92F ” on page 115.
• All SAS cables were removed, as described in “Removing and installing a SAS cable: 2076-92F ” on
page 76.
• The following FRUs were removed from the enclosure, as described in the applicable tasks:
– Top cover (“Removing the top cover: 2076-92F ” on page 46)
– Drives (“Removing a drive: 2076-92F ” on page 90)
– PSU (1U) fascia (“Removing the fascia: 2076-92F ” on page 74)
– Power supply units (“Removing a power supply: 2076-92F ” on page 89)
– Secondary expander modules (“Removing a secondary expander module: 2076-92F ” on page 93
)
– Expansion canisters (“Removing an expansion canister: 2076-92F ” on page 96)
– Fan modules (“Removing a fan module: 2076-92F ” on page 98)
• The expansion enclosure was removed from the rack, as described in “Removing an expansion
enclosure from a rack: 2076-92F ” on page 83.
• A suitably rated mechanical lift is available to support the weight of the enclosure.
About this task
The expansion enclosure contains the drive board, signal interconnect board, and internal power cables.
If a fault with the drive board or the intercanister link is suspected, you can replace the enclosure.
However, you can remove the parts from the old expansion enclosure and reinstall them in the
replacement enclosure.
Procedure
1. Remove the front display (4U) and PSU (1U) fascia from the old enclosure, as described in “Removing
the fascia: 2076-92F ” on page 74.
a) Install the front display (4U) and PSU (1U) fascia on the new enclosure, as described in “Installing
or replacing the fascia: 2076-92F ” on page 70.
2. Remove the display panel assembly from the old enclosure, as described in “Removing the display
panel assembly: 2076-92F ” on page 105.
a) Install the display panel assembly into on the new enclosure, as described in “Installing or
replacing the display panel assembly: 2076-92F ” on page 107.
3. Remove the fan interface boards from the old enclosure, as described in “Removing a fan interface
board: 2076-92F ” on page 100.
a) Install the fan interface boards into on the new enclosure, as described in “Installing or replacing
a fan interface board: 2076-92F ” on page 80.
4. Remove the inner section of the slide rail from the old enclosure, as described in “Removing the
support rails: 2076-92F ” on page 109.
5. Attach the inner rail section to the new enclosure, as described in “Installing the support rails:
2076-92F ” on page 26.
104
Storwize V7000 : Gen3 Quick Installation Guide for MTM 2076-724, 2076-U7B, 2076-12F, 2076-24F, and
2076-92F
