IBM System Storage TS3400 Tape Library - Back Board Connectors; Back Board

9-42 TS3400 Tape Library Maintenance Information
Figure 9-48. Back board connectors
Figure 9-49. Back board flat cable connector lock tab
17. Remove the five screws securing the back board ( in Figure 9-50) to the power
supply housing, and lift the back board out.
a34z0154
a34z0171
1
1
