8. Grasp the EIA assembly and pull it slightly forward to remove it from the
server.
9. If you are instructed to return the EIA assembly, follow all packaging
instructions, and use any packaging materials for shipping that are supplied to
you.
Cable arm cover
Figure 145. Cable cover removal
EIA assembly
Figure 146. EIA assembly removal
210 System x3650 M5 Type 5462: Installation and Service Guide
