19
CONTROL COMMAND
19-8
Remote control (CI-V) information (Continued)
D Data content description
• Operating frequency
Command: 00, 03, 05, 1C 03
q
XXXXX
we
X
rt
X
X0
0
10 Hz digit:
0–9
1 Hz digit:
0–9
1 kHz digit:
0–9
100 Hz digit:
0–9
100 kHz digit:
0–9
10 kHz digit:
0–9
10 MHz digit:
0–6
1 MHz digit:
0–9
1000 MHz digit:
0
(Fix
ed)
100 MHz digit:
0
(Fix
ed)
• Operating mode
Command: 01, 04, 06
Filter setting (w) can be skipped with command 01
and 06. In that case, “FIL1” is selected with command
01 and the default lter setting of the operating mode
is automatically selected with command 06.
q
XXXX
w
q Operating mode w Filter setting
00: LSB 05: FM 01: FIL1
01: USB 07: CW-R 02: FIL2
02: AM 08: RTTY-R 03: FIL3
03: CW
04: RTTY
• SSB/SSB-D transmission passband width settings
Command : 1A 050014, 050015, 050016, 050196
XX
Higher edge: 0= 2500 Hz
1= 2700 Hz
2= 2800 Hz
3= 2900 Hz
Lower edge: 0= 100 Hz
1= 200 Hz
2= 300 Hz
3= 500 Hz
• RX HPF/LPF setting for each operating mode
Command : 1A 050001, 050004, 050007, 050010,
050011
X X X X
LPF (Upper edge)
HPF (Lower edge)
*The value of the HPF should be smaller than the LPF.
HPF
00: Through
01~20: 100~2000 Hz
LPF
05~24: 500~2400 Hz
25: Through
• Bandscope edge frequency settings
Command: 1A 050112~050150
1 kHz: 0–9 100 Hz: 0 (fixed) 100 kHz: 0–9 10 kHz: 0–9 10 MHz: 0–6 1 MHz: 0–9 1 kHz: 0–9 100 Hz: 0 (fixed) 100 kHz: 0–9 10 kHz: 0–9 10 MHz: 0–6 1 MHz: 0–9
q
X 0 X X X X X 0 X X X X
w e r t y
Lower edge Higher edge
• Color settings
Command : 1A 050104, 050105, 050106, 050152,
050154, 050167, 050171, 050172
q
0 XXX0XXX0 XXX
werty
R (Red)
0000–0255
G (Green)
0000–0255
B (Blue)
0000–0255
• Band edge frequency settings
Command : 02*, 1E 01, 1E 03
q
X X X
w e r t y u i o !0 !1 !2
X X X X X X X 0 0 2 D X X X X X X X X 0 0
10 Hz digit: 0–9 1 Hz digit: 0–9 1 kHz digit: 0–9 100 Hz digit: 0–9 100 kHz digit: 0–9 10 kHz digit: 0–9 10 MHz digit: 0–6 1 MHz digit: 0–9 1000 MHz digit: 0 (fixed) 100 MHz digit: 0 (fixed) 10 Hz digit: 0–9 1 Hz digit: 0–9 1 kHz digit: 0–9 100 Hz digit: 0–9 100 kHz digit: 0–9 10 kHz digit: 0–9 10 MHz digit: 0–6 1 MHz digit: 0–9 1000 MHz digit: 0 (fixed) 100 MHz digit: 0 (fixed) Separator (fixed)
Lower edge Higher edge
Edge number*: 01–30
