vi
DESCRIPTION INFORMATION
This instruction manual is described based on the following manner.
“ ” (Quotation marks): Used to indicate icons, setting items, and screen titles displayed on the screen.
[ ] (brackets): Used to indicate keys, dials, and knobs.
Routes to the Set mode and setting screen descriptions
Routes to the Set mode, setting screen and the setting items are described in the following manner.
About the transceiver’s illustrations
To indicate the keys and knobs in the operating steps, the transceiver is illustrated as illustrated below.
Band edge warning beep
This function allows you to hear a beep tone when
you tune in or out of an amateur band’s frequency
range. A regular beep sounds when you tune into a
range, and a lower tone error beep will sound when
you tune out of a range.
The Multi-function screens are OFF:
Select the “Beep (Band Edge)” item in the Others q
set screen.
SET [F-7] OTHERS [F-5] Beep (Band Edge)
Rotate [MAIN DIAL] to select the option. w
• Band Edge Beep options:
OFF: Band edge beep is OFF.
ON (Default): When you tune into or out of the de-
fault amateur band’s frequency range,
a beep sounds. (default)
SET [F-7]
OTHERS [F-5]
Beep (Band Edge)
The Set mode menu screen.
The Multi-function screens are OFF.
The Others set screen.
(
) Multi-function keys Band key
(F) Function keys Mode keys
Also, the keys and knobs are described in the following
manner.
() Multi-function keys
Example:
Push the Multi-function [METER]() key.
(F) Function key
Example: Push [SCOPE](F).
Mode key
Example: P
ush the Mode key [SSB].
