KEY ICON DESCRIPTION
The keys are described in this manual as follows:
The keys that have words or letters on them are
described with the characters “[ ].”
Example: [ENT], [CLR]
The Software Keys are described with the words or
letters on a blue background, such as
or
.
The functions of the keys are shown at the bottom of
the display. Push the key below the desired function.
You can use the following keys on the Menu screen.
FUNCTION ACTION
Select
Enter
Push [ENT], [CH/GRP], or
.
Go to the next tree level
or
.
Go back to the previous
tree level
.
Cancel Push [CLR].
Exit
Push
.
The following action icons describe [CH/GRP], [ENT],
z Rotate
: Rotate [CH/GRP] to select.
z Push : Push [ENT] to enter or set.
z Push : Push the Keypad keys to enter a
digit or text.
z Push
:
RECOMMENDATION
CLEAN THE REMOTE CONTROLLERʼS
FRONT PANEL THOROUGHLY IN A BOWL OF
FRESHWATER after exposure to saltwater, and dry
keys, switches may become unusable, due to salt
L The connectors on the rear panel do not meet IPX7
.
NOTE: If the remote controller’s waterproof
protection appears defective, carefully clean it with
a soft, damp (freshwater) cloth, then dry it before
operating. The remote controller may lose its
waterproof protection if the case or connector cover
is cracked or broken, or the remote controller has
been dropped. Contact your Icom distributor or your
dealer for advice.
ABOUT CE AND DOC
Hereby, Icom Inc. declares that the
versions of IC-M804 which have the “CE”
symbol on the product, comply with the
essential requirements of the Radio
Equipment Directive, 2014/53/EU, and the restriction
electrical and electronic equipment Directive, 2011/65/
EU. The full text of the EU declaration of conformity is
available at the following internet address:
https://www.icomjapan.com/support/
DISPOSAL
The crossed-out wheeled-bin symbol
on your product, literature, or
packaging reminds you that in the
European Union, all electrical and
electronic products, batteries, and
accumulators (rechargeable batteries)
must be taken to designated collection locations at the
end of their working life. Do not dispose of these
products as unsorted municipal waste.
Dispose of them according to the laws in your area.
