System Hardware and Installation Tunnel Master
Jr. User Manual—Version 3.0
34 January 2016
PUSH BUTTON WIRING
If the Tunnel Master
Jr. is going to utilize a Push Button Station as a means of
remotely selecting the features of each car wash, refer to one of the following
schematic diagrams of how it must be wired to operate correctly with the
inputs of the Tunnel
Master
Jr.
!
IMPORTANT: Please be certain to install it exactly as it is
shown in the diagram. Wiring it in any other way would
conflict with the designated inputs causing the washes
to run incorrectly or not at all.
