User Manual—Version 3.0 Tunnel Master
Jr. Entrance Keypad
January 2016 67
The following buttons are the functions for the Entrance Keypad.
NOTE: All buttons, with the exceptions of the AC, and $ (dollar) buttons,
have red indicator lights in the upper left-hand corner of the button.
These red indicators will light after the button is selected and stay lit
until the vehicle has started through the gate switch
and reached
minimum car length.
NOTE: To clear a button selected in error, simply press the button again, and
the LED light will go out.
You can add services, remove services, select retracts, and remove a car from
the stack with the Entrance Keypad. First, setup your Relay Box to Keypad
for
stacking.
Table 17: Entrance Keypad Buttons
Button Function
After all desired services have been entered, but before the
Roller button is pressed, press the $ (dollar) button to confirm
services. If optional printer is available, a receipt will print too.
Numeric buttons (1-16) are used to program services or retracts
into system prior to processing
vehicle.
The car is the Roller button and when selected will activate the
roller relay.
In ICS-POS mode, when the AC button is selected, the stack
displays in blinking Led lights on the numeric buttons. Number
one is the closest
to the tunnel entrance. The stack blinks
for 5 seconds.
