Entrance Keypad Tunnel Master
Jr. User Manual—Version 3.0
68 January 2016
ENTRANCE KEYPAD TO PROCESS VEHICLES (NON-STACKING)
These are the steps to follow for a non-stacking system.
Table 18: Process Vehicles (Non-Stacking)
Step Non-Stacking Action Keypad Response
1 On the numeric keypad, press the button
associated with the service the customer has
purchased.
The red indicator light will light up indicating the
input has been accepted.
2 Press any additional extra service buttons for
other services the customer may have
purchased.
The red indicator light will light up for each
additional service button pressed indicating the
input has been accepted.
3 Press the Receipt button to print a customer
receipt, if there is a receipt printer attached to
the
Entrance Keypad.
Customer r eceipt will print out.
4 Once all desired services are “loaded”, press the
“Roller ” button to start the vehicle through the
wash.
NOTE: Once the roller button has been pressed
the roller relay will be activated and a roller will
come up to process the vehicle
through the wash.
The indicator light on the roller button will light up
indicating that the input has been acc epted.
5 Vehicle will start through the wash breaking
the gate switch.
NOTE: All the indicator lights will sta y lit until
there has been enough chain travel to reach
minimum car length set in wash settings.
All indicator lights will go out after the car has
reached minimum car length.
