ICS Tunnel Master Jr User Manual

User Manual—Version 3.0 Tunnel Master

Jr. Wash Configuration
January 2016 63
ASSIGN OUTPUTS TO SERVICES
Follow these procedures to set or change the Outputs that will be activated
for the various service options.
12 Using the numeric buttons enter the desired tax
rate option, 0, 1, 2, or 3.
Service 01 Name GOLD WASH Price 9.99Type B
Rate 1
F1=PREV F2=NEXT F3=ERASE F4=SAVE
13 Press the F4 button to save the service. Service 01 Name GOLD WASH Price 9.99Type B
Rate 1
F1=PREV F2=NEXT F3=ERASE F4=SAVE
14 Press the MENU button to return to the previous
menu screen.
[1] Services[4] Wash Settings
[2] Outputs[5] Set Date Time
[3] Output Lists[6] Set Password
Table 15: Change or Set Services Instructions
Step Action Screen Displays
Table 16: Assign Outputs to Services Instructions
Step Action Screen Display
1 Press the MENU button from the
main screen display.
[1] Shift Break[4] View Counts
[2] Wet Down Wash[5] Print Reports
[3] Configure Wash
2 Press the numeric key 4 to select the Configure
Wash menu option.
[1] Service[4] Wash Settings
[2] Outputs[5] Set Date Time
[3] Output Lists[6] Set Password
3 Press the numeric key 3 to select the Output
Lists menu option.
Service _ _
Outputs
4 Using the numeric keypad enter the PLU# of the
service to be programmed.
Service 03
Outputs
5 Press the ENT button on the display pad to
advance to the next setting.
Service 03
Outputs _ _
6 Using the numeric buttons enter in the number
corresponding to the Selective or Deselective
output the user wishes to have activated when
this
service is processed.
Service 03
Outputs 05,
