Entrance Keypad Tunnel Master
Jr. User Manual—Version 3.0
70 January 2016
2 Press to select the numeric button that represents the car in the stack you
would like to modify.
The service that is selected for that car will light up on the keypad.
3 If necessary, press to select the numeric button of the service you
wish to
clear.
4 If necessary, press to select the numeric button of the new wash service or
retract you wish to select.
5 Press the $ (dollar) button to confirm the wash selection.
The lights will flash again displaying the cars on stack.
NOTE: Setup for Retracts is on the Tunnel Master
Jr. services page.
Add a Car to Stack
To add a new car to the end of the stack, follow these steps:
1 On the keypad, press a numeric button to select a service.
2 Press the $ (dollar) button.
LED lights blink for five seconds displaying the cars currently
in the stack.
The newly added car with the service is added to the end of the stack.
Remove a Car from Stack
Select the car in the stack, remove the service, and then confirm. At that
point, the car will no longer be in the stack.
1 On the
keypad, press the AC button.
2 Select the lit up button(s) or services to clear.
The button’s light(s) will go out.
3 Press to select the $ (dollar) button.
The stack will blink and you will no longer see the car you removed light
up and the cars move up in the stack. (i.e. if you had three cars on stack in
position 1, 2 and 3 shown on the numeric keypad, and you removed the
2nd car. Then only lights 1 and 2 will be lit.)
