ICS Tunnel Master Jr User Manual

Wash Configuration Tunnel Master

Jr. User Manual—Version 3.0
58 January 2016
OUTPUT SETTINGS
Follow these procedures to set or change the settings for the Outputs in the
Tunnel Master

Jr. Controller program.
Table 13: Output Settings
Step Action Screen Displays
1 Press the MENU button from the main screen
display .
[1] Shift Break[4] View Counts
[2] Wet Down Wash[5] Print Reports
[3] Configure Wash
2 Press the number 3 key to select the Configure
Wash menu option.
[1] Services[4] Wash Settings
[2] Outputs[5] Set Date Time
[3] Output Lists[6] Set Password
3 Press the number 2 key to select the Outputs
menu option.
Output _ _Name _ _ _ _ _ _ _ _ _ _ Start _ _ Type _
Part _ _ Flash _
Extend _ _ _ _ Look _ _ _ Wet _ Panic _ - _ _
F1=PREV F2=NEXT F3=ERASE F4=SAVE
4 From the numeric keypad, type the desired
number for the output.
NOTE: See “Wash Configuration” on page 43.
Output 01 Name _ _ _ _ _ _ _ _ _ _ Start _ _ Type _
Part _ _ Flash _
Extend _ _ _ _ Look _ _ _ Wet _ Panic _ -
_ _ F1=PREV F2=NEXT F3=ERASE F4=SAVE
5 Press the ENT button on the display keypad to
advance to the next setting.
Output 01 Name
Start _ _ Type _ Part _ _ Flash _
Extend _ _ _ _ Look _ _ _ Wet _ Panic _ - _ _
F1=PREV F2=NEXT F3=ERASE F4=SAVE
6 From the numeric buttons, type the number of the
Output.
Output 01 Name Roller
Start _ _ Type _ Part _ _ Flash _
Extend _ _ _ _ Look _ _ _ Wet _ Panic _ - _ _
F1=PREV F2=NEXT F3=ERASE F4=SAVE
7 Press the ENT button on the display pad to
advance to the next setting.
Output 01 Name Roller
Start _ _ Type _ Part _ _ Flash _
Extend _ _ _ _ Look _ _ _ Wet _ Panic _ - _ _
F1=PREV F2=NEXT F3=ERASE F4=SAVE
