Wash Configuration Tunnel Master
Jr. User Manual—Version 3.0
60 January 2016
Services menu option is where the user will initially setup and edit the wash
services that will be available on the system. The basic controller
configuration allows for up to 16 services, and the roller control as service 17.
There is an option to
add an additional entrance Keypad that will provide for
an additional 16 services for a total maximum of 32 services.
NOTE: YOU MAY NOT MAKE CHANGES TO THE SERVICES WHILE IN A
SHIFT. THE CAR COUNT MUST BE 0. YOU MAY BUMP A SHIFT AT
THE KEYPAD OR THE RELAY BOX.
See “Bump a Shift or Manually Close Current Shift” on page 77.
The following table is a list of menu items within the Services menu and a
brief explanation of their function.
14 From the numeric keypad, type the number of
seconds of delay for this relay to turn on before
the convey
or will restart.
NOTE: If you do not wish this relay to stagger start,
enter 0.
Output 01 Name Roller
Start 0084 Type R Part AC Flash N
Extend 000
Look 000 Wet N Panic N - 0
F1=PREV F2=NEXT F3=ERASE F4=SAVE
15 Press the F4 button to save
the service.
Output _ _Name _ _ _ _ _ _ _ _ _ _
Start _ _ Type _
Part _ _ Flash _
Extend _ _ _ _ Look _ _ _ Wet _ Panic _ - _ _
F1=PREV F2=NEXT F3=ERASE F4=SAVE
16 Press the MENU button to return to the previous
menu screen.
[1] Services[4] Wash Settings
[2] Outputs[5] Set Date Time
[3] Output Lists[6] Set Password
Table 13: Output Settings
Step Action Screen Displays
Table 14: Services Menu Item Descriptions
Menu Item Function
Service Enter a numeric value of 01 up to 16. These numbers represent the wash services options
that will be available and their location on the Entrance Keypad. The numbers represent
a PLU # or Price Look Up for the system to refer to when displaying and printing reports.
Name Use the numeric keys to enter the name of the service to be programmed.
