Idis DR-6532P - Idla_Intrusion

Part 2 - Conguration
74
IDLA_Intrusion
● No.: Select which cameras to apply Intrusion to. It is
activated only when the analytic type is set to Intrusion
in the Device - VA Box- Setup tab.
● CAM: Indicates the camera channel. VA BOX title is
displayed next to the camera channel number.
Refer
to the VA Box_Setup on page 88 for basic
information on setting the VA BOX.
● Zone: Set a zone to be detected as a polygon.
You can set a zone using the mouse. The zone is
displayed in transparent. Drag and drop the vertex to
modify the zone.
Right-click on the zone setup screen to bring up the
Intrusion Menu.
– Zone Title: Select the zone to change the settings.
When selecting the zone, a check mark appears to
the left.
– Clear: Clear the selected zone.
– Undo: Remove the last point of a line.
– Edit Name: Change the name of the zone.
– Object: Select an object to detect.
– Direction: Select the direction of the obejct to
detect.
– Add: Add a zone.
– Delete: Delete the selected zone.
– Delete All: Delete all zones.
– Save: Save the changes and exit the menu.
– Cancel : Exit the setup screen without saving the
changes.
● Ignore Condition: Set the condition to ignore them
when the events occur.
– Ignore Condition: The system does not produce
event log entries or issue remote notications
regarding event for the specied time after the
initial event was detected. Set the value between 1
sec and 5 secs or choose Never. Ignore Condition
does not aect Intrusion recording.
– Use Ignoring Time: Intrusion function will be
disabled during the specied time.
● Actions: Specify which actions to take when the
function is detected.
– Record: Specify which cameras to begin linked
recording on when an event occurs. If the schedule
is set to Event or Time & Event mode, the selected
cameras will begin linked recording when an event
occurs.
– Alarm-Out: Designate event-triggered alarm-out
channels (each for the NVR and camera) and beeps.
– Notify: Congure to be notied of events by Mail,
LAN1 through 5, Push, FTP, and/or Alert Window.
– PTZ: Moves the PTZ camera to a specic preset
position when an event occurs.
– Event Monitoring: Selects the cameras to monitor
when an event occurs.
