IDS 400 User Manual

IDS Base Station Receiver 400 700-179-02B Issued January 2009 52
Where:
 A Alarm
 R Restore
NOTE:
::
:
Code changes and additions from Ver 3.06 onwards:
 Line Loss code changed from 21...24 to 20.
 Line Restore code changed from 31...34 to 30.
 Power up status message reported.
 The ERROR event data received by a line card output, when enabled, has been changed to a
“System Message” code 10.
 The “System Message” code 40, “Missed Call” (No data received) has been added and will be
output when enabled.
 Line card number is included in the “System Messages” preamble PRRL, where L will be the
related line card number.
4.6.16
4.6.164.6.16
4.6.16 SIA
SIASIA
SIA-
--
-ID Protocol 1 [3]
ID Protocol 1 [3]ID Protocol 1 [3]
ID Protocol 1 [3]
The IDS BSR400 sets the RR and L to the source of the received event, changes any account code value
“A” to a “0” and outputs the remaining information as received.
PRRLssssAAAAAAXXYYYY{DC4} – Where
 P 3 - Protocol Identifier Number - SIA Protocol 1
 RR - Receiver number
 L - Line number
 s - Space
 AAAAAA - Six digit account code. Leading spaces will be sent if the account code is less than
six digits.
 XX - SIA event code. Leading spaces will be sent if the account code is less than four
digits.
 YYYY - Zone codes.
 {DC4} - Terminator, 14 hex (^T), acknowledge with (^F)
4.6.17
4.6.174.6.17
4.6.17 SIA
SIASIA
SIA-
--
-ID Protocol 2 [S]
ID Protocol 2 [S]ID Protocol 2 [S]
ID Protocol 2 [S]
The SIA Protocol 1 cannot handle cretin information in SIA level 2 and 3. Where these levels are used the
SIA Protocol 2 must be selected, see 4.6.8 Sout Option M419. The IDS BSR400 sets the RR and L to the
source of the received event, changes any account code value “A” to a “0” and outputs the remaining
information as received.
PRRL[#AAAAAA|EMMZZZZ/MMZZZZ/MMZZZZ]{DC4} – Where
 P S - Protocol Identifier Number - SIA Protocol 2
 RR - Receiver number
 L - Line number
 [ - Beginning data delimiter
 AAAAAA - Account code, maximum sixteen digits.
 | - Field separator
 MM - Event code or modifier.
 ZZZZ - Zone codes, or user code, or date and time information.
 / - Data code packet separator.
 ] - Ending data delimiter.
