IDS 400

IDS Base Station Receiver 400 700-179-02B Issued January 2009 42
Table 8: Contact ID [10x...42x] Event Type Buzzer Enable
Group 10 11 12 13 14 15-16 20-21 30-31 32 33-34 35-36 37 38 40 41 42
Header 0 1 2 3 4 5 6 7 8 9 A B C D E F
Tag 1 1 1 1 0 0 0 1 0 1 1 0 0 0 0 0
Table 9: Contact ID [44x...63x] Event Type Buzzer Enable
Group Code 44-45 50-51 52 53-54 55-56 57 60-63
Field Header 0 1 2 3 4 5 6
Tag Value 0 0 0 0 0 0 0
Contact ID tagged field 1 example:
ALARM EVENTS
Tagged CID 1
(1111000101100000)
Press *
ALARM EVENTS
0123456789ABCDEF
(1111000101100000)
_---------------
Press 5 until the “Header” number to be changed is reached and enter the new tag value. Press
6 or 5 to select other header fields. Press 5 until the last field, then press * to save and
end entry process.
Table 10: Contact ID Group Event Codes
Group Codes
Group CodesGroup Codes
Group Codes Default
DefaultDefault
Default Table
TableTable
Table
Ref
RefRef
Ref
Group Descripti
Group DescriptiGroup Descripti
Group Description
onon
on
10x 1 7-0 Medical
11x 1 7-1 Fire
12x 1 7-2 Panic
13x 1 7-3 Burglar
14x 0 7-4 General
15x – 16x 0 7-5 24 Hour Non- Burglary
20x – 21x 0 7-6 Fire Supervisory
30x – 31x 1 7-7 System Trouble
32x 0 7-8 Sounder/Relay Trouble
33x – 34x 1 7-9 System Peripheral Trouble
35x – 36x 1 7-A Communication Trouble
37x 0 7-B Protection Loop Trouble
38x 0 7-C Sensor Trouble
40x 0 7-D Open/Close
41x 0 7-E Remote Access
42x 0 7-F Access Control
44x – 45x 0 8-0 Special O/C
