IDS 400

IDS Base Station Receiver 400 700-179-02B Issued January 2009 49
4.6.8
4.6.84.6.8
4.6.8 Sout Option
Sout OptionSout Option
Sout Option M419
M419M419
M419
The “Sout Option” menu function is a bit field selection available for version V3.00and higher to select the
following options:
 Select SIA Level 1 or 2 serial output format.
The menu functions that where available for version V2.05 that effect more than just the serial output
process have been moved to 4.3.7 Format Options M107.
 SIA Output Format
The IDS BSR400 supports “Level 1” and “Level 2” serial output
• 0 – Protocol 1 SIA serial output.
• 1 – Protocol 2 SIA serial output (Default).
Bit 1
Default Value 1
Table 18: Serial out Options
Bit
BitBit
Bit Function
FunctionFunction
Function
1 SIA Protocol 1 or 2
0 -- Protocol 1 SIA serial output.
1 – Protocol2 SIA serial output (Default)
SYSTEM
These settings enable the user to adjust the serial communication (Sout
SoutSout
Sout) timing to match the operating
rate of the monitoring process.
 The inter-record and inter-character setting.
 The rate at which the Heart Beat is output when there is no activity.
 The period the base station will wait for an Acknowledgement.
4.6.9
4.6.94.6.9
4.6.9 Delay between Sout
Delay between Sout Delay between Sout
Delay between Sout M421
M421M421
M421
The inter-record setting changes the period between records from [00...39]
[00...39][00...39]
[00...39] in 15 millisecond intervals
and an inter-character period is automatically added depending on the inter record period selected.
 Default = 0.
 [00...39] = 000 to 585 milliseconds.
Inter Character Period
• 000 = No inter character period
• 1...5 = One character period
• 6...10 = Two character period
• >10 = Three character period
