NOTE 2:
Some “Monitoring Programs” concatenate the “Event Code Identifier” X and Zone/User/Event Number.
 4/1 Format
Table 14: 3x1 and 4x1 Serial Event Code Identifier
RECEIVED EVENT 1 2 3 4 5 6 7 8 9 A B C D E F
DEFAULT EVENT ID
 4/2 Format
Table 15: 4x2 Serial Event Code Identifier
RECEIVED EVENT 1 2 3 4 5 6 7 8 9 A B C D E F
DEFAULT EVENT ID
 4/3 Format
Table 16 :4x3 Serial Event Code Identifier
RECEIVED EVENT 1 2 3 4 5 6 7 8 9 A B C D E F
DEFAULT EVENT ID
Table 17: Event Codes Identifiers
0 Automatic test
1 Fire alarm
2 Panic alarm
3 Burglary alarm
4 Arming by User
5 Disarming by user
6 Service
7 Medical Emergency
8 Message
9 Restore
A Alarm
B Bypass
C Arming by user
F Auxiliary
H Nubians
O Disarming by user
R Restore
T Trouble
Z Common event code
NOTE:
 In the case where the “X” code is added to the event code by the monitoring software enter a
“Space” character to all the format fields above effectively deleting the code.
 Depending on how the event code identifier is used, entering an “A” in all the format fields above
could be used to change the received event code from “6F” to “A6F” or “06F” where “A” is
converted to a “0”.
 The above to case may be use to change an event code “A6F” to “R6F” required by the
monitoring software.
