IDS 400 User Manual

IDS Base Station Receiver 400 700-179-02B Issued January 2009 9
 Printer Peripheral Interface (Pout)
• 1 Parallel printer port for event output with or without configurable “Plain Text Library”
 RS232 Serial Communication Port 1 (Sout) for PC monitoring programme
 9600 Baud, 8 bits, 1 Stop bit and No parity supporting the following protocols:
• 1 - Basic Signal Protocol
• 1 - Supervisory Poll (Heart beat) Signal Protocol. For continuous verification of the
computer-receiver link by polling during in-active periods
• 1 - Status Report Messages
• 3 - SIA-ID Protocol 1
• S - SIA-ID Protocol 2
• 4 - Telephone Number Protocol (Call ID)
• 5 - Contact-ID Protocol
• Configurable serial date output: Enable/disable, pre or post fix and enable/disable year
output
• Enable/disable Caller ID output (Telephone Number Protocol)
 RS232 Serial Communication Port 2 (Sin
SinSin
Sin) for IDS BSR400 stacking
 9600 Baud, 8 bits, 1 Stop bit and No parity for the following:
• Base-to-Base communication for extending the number of lines handled by one serial port
• Printer formatted events output if the base-to-base is not been used
 Line Card with multiple alarm panel communication formats:
• 1 to 4 line cards per receiver
• Caller Identification (Call Display) ability
• Telephone line supervision on all line cards
• 3X1 Pulse formats
• 4x1 Pulse formats
• 4X2 Pulse formats with or without checksum
• Sescoa Superfast 3x3 Pulse format with checksum
• Ademco express 4X2 DTMF
• Contact ID (DTMF)
• SIA Level 1 and 2 (100 or 300 Baud FSK)
2.
2.2.
2. I
II
Installation
nstallationnstallation
nstallation
There are three installation variations of the IDS Base Station Receiver apart from the optional number of
Line Cards used.
 Standalone: IDS BSR400 only
 Intermediate: IDS BSR400 plus a printer
 Full Installation: IDS BSR400 plus a printer and PC based Alarm Monitoring program
2.1
2.12.1
2.1 Full
Full Full
Full Installation Requirements
Installation RequirementsInstallation Requirements
Installation Requirements
 IDS Base Station Receiver 400
 Mains supply:
• IDS BSR - IDS 32VA 16V Wall Mounted Transformer T.
• IDS BSR400 – 220V 50Hz AC kettle sock and manes plug cable M.
 1 to 4 Phone cables terminated with Venice connectors as required. L1...4
