4.1.3 Program Mode Menu
Program Mode MenuProgram Mode Menu
Program Mode Menu
The program mode consists of non-variable primary and secondary headings identified as all upper case
characters and the programmable settings in the “Title” format.
Table 3: Program Mode Menu
P
PP
P
Primary
PrimaryPrimary
Primary S
SS
S Sec
SecSec
Sec D
DD
D Data
Data Data
Data Settings
SettingsSettings
Settings Add
AddAdd
Add Default
DefaultDefault
Default User Value
User ValueUser Value
User Value
0 FIRMWARE VERSION M000
1 STATION SETUP M100
1 Station ID M101 01
2 Master ID M102 9999
3 Date M103
4 Time M104
5 Load Defaults M105
6 Clr Un-viewed Count M106
7 Format Options M107 0000 011
2 PRINTER SETUP M200
1 Enable Printer M201 00
2 Plain Library M202 0
3 Plain Library Setup M203 123456789ABCDF
3 ALARM EVENT SETUP M300
1 Event Buzzer M301 0
2 Relay Output M302 0
3 Tagged Events M303 1110 0111 1000 001
4 Tagged CID 1 M304 1111 0001 0110 0000
5 Tagged CID 2 M305 0000 000
6 Tagged SIA 1 M306 1111 0111 0000 1000
7 Tagged SIA 2 M307 0000 0000 00
8 Wake-up Alarm M308 0
4 SERIAL OUT SETUP M400
1 1 Enable COM M411 1
1 2 Event Date/Pre/Post M412 0
1 3 Poll Date /Pre/Post M413 0
1 4 Enable Year Output M414 0
1 5 Enable CALL ID M415 0
1 6 4/1 Format M416 (All spaces)
1 7 4/2 Format M417 (All spaces)
1 8 4/3 Format M418 (All spaces)
1 9 Serial Options M419 1
2 1 Delay Between Sout M421 0
2 2 Heart Beat Period M422 30
2 3 Ack Wait Period M423 6
2 4 Event/Ack Repeats M424 3
5 LINE CARD SETUP M500
1 LC 1 Each with M510
2 LC 2 sub-menus M520
3 LC 3 shown M530
