IDS Base Station Receiver 400 700-179-02B Issued January 2009 53
{DC4} - Terminator, 14 hex (^T), acknowledge with (^F)
The length of the signal varies and it can support a maximum of 63 byte data blocks.
4.6.18
4.6.184.6.18
4.6.18
Telephone Number Protocol (Call ID) [4]
Telephone Number Protocol (Call ID) [4]Telephone Number Protocol (Call ID) [4]
Telephone Number Protocol (Call ID) [4]
The IDS Base Station Receiver will send the following messages to Sout Port to report the “Caller
Identification” phone number when enabled. The control process waits for the accompanying event,
extracts the account code and adds this to the sequence. If the event is not received in the defined time
the process outputs “FFFF” account code.
The line number will be fixed to be “0”.
PRRLAAAAAALLLTTTTTTT[DC4] Where:
4 - Protocol Identifier Number
RR - Receiver number
L - Line number
AAAAAA - Account code, usually 4 digits with 2 leading spaces [...0000]
LLL - Long distance code
TTTTTTT - Local telephone number
[DC4] - Terminator, 14 hex (^T), acknowledge with (^F)
4.6.19
4.6.194.6.19
4.6.19
Contact
ContactContact
Contact-
--
-ID Protocol [5]
ID Protocol [5]ID Protocol [5]
ID Protocol [5]
The IDS BSR400 sets the RR and L to the source of the received event, changes any account code value
“A” to a “0” and outputs the remaining information as received.
PRRLs18AAAAQXYZGGCCC[DC4] – Where
P 5 - Protocol Identifier Number
RR - Receiver number
L - Line number
s - Space
18 - Contact-ID format identifier
AAAA - Four digit account code
Q - Qualifier
E - New event or opening
R - New restore or closing
P - Previous event
XYZ - Class code and event code
GG - Group number
CCC - Zone codes or user ID.
[DC4] - (^T), acknowledge with (^F)
4.7
4.74.7
4.7 L
L L
Line
ine ine
ine C
CC
Cards
ardsards
ards S
S S
Setup
etupetup
etup
M500
M500M500
M500
The IDS Base Station Receiver handles four Line Cards 1...4. Each has seven settings, see below:
4.7.1
4.7.14.7.1
4.7.1
Handshake O
Handshake OHandshake O
Handshake Order
rder rder
rder M5x1
M5x1M5x1
M5x1
Often it is important which handshake is sent first. This option selects the order in which the handshakes
are sent. Default is 2314.
0 – disables the handshake
1 – Dual tone handshake
