IDS 400 User Manual

IDS Base Station Receiver 400 700-179-02B Issued January 2009 45
The IDS BSR400 requires an acknowledge signal [ACK] from the computer software within six seconds
(default) for each message sent. Failure to receive an [ACK] will initiate a maximum of 3 additional
attempts to resend the message. The IDS BSR400 can stores over a 1 000 messages in non-volatile
memory and these statuses and events will automatically be sent to the PC when serial communication is
re-established.
The status of the serial communication with the PC is reported as a “System MSG” on the panel display,
COMMS ABSENT
COMMS ABSENTCOMMS ABSENT
COMMS ABSENT or COMMS Rest
COMMS RestCOMMS Rest
COMMS Restored
oredored
ored.
The events stored in the event log may be re-output to the PC from the “Standby mode” using the 4.6.2
Enable Serial M411function to select an operation period once serial communications have been
established.
The IDS BSR400 has a Date Stamp (date, time, and year) option that may be enabled as a pre-fix or
post-fix to either the event or heart beat (poll) outputs or both. The serial protocol must be as follows:
 9600 baud
 1 start bit
 8 data bits
 1 stop bit
 No parity
4.6.1
4.6.14.6.1
4.6.1 F
FF
Format
ormatormat
ormat M41x
M41xM41x
M41x
The following setting facilitates enabling/disabling and configuring the serial output format.
4.6.2
4.6.24.6.2
4.6.2 Enable Serial
Enable Serial Enable Serial
Enable Serial M411
M411M411
M411
The serial event output port on SOUT PORT to the PC is enabled by entering 01 or the user has the
option to enter a test period 02...99 minutes during which the user may output logged events from the
“Standby Mode”. This function may be used at any time, once serial communications have been
established, to output missed events or re-output logged events to test the connection to the monitoring
program. Enter 0 to disable the serial output.
 00 – Disable serial event output (default)
 02…99 Enables serial event output period in minutes.
NOTE:
• The requested number of events to be output will revert to the number of events in the log if
the requested number exceeds the number of events in the log.
• The control process saves 1 in the program memory for any value greater than 1.
4.6.3
4.6.34.6.3
4.6.3 Event Date/Pre/Post
Event Date/Pre/Post Event Date/Pre/Post
Event Date/Pre/Post M412
M412M412
M412
The Date Stamp option may be pre or post fixed to the PC event protocol output.
 0 – Disables Date Stamp (default)
 1 - Enables Prefix Date Stamp.
 2 - Enables Postfix Date Stamp.
4.6.4
4.6.44.6.4
4.6.4 Heart Beat (Poll) Date/Pre/Post
Heart Beat (Poll) Date/Pre/Post Heart Beat (Poll) Date/Pre/Post
Heart Beat (Poll) Date/Pre/Post M413
M413M413
M413
The Date Stamp option may be pre or postfixed to the PC heart beat (poll) protocol output.
 0 – Disables Date Stamp (default)
 1 - Enables Prefix Date Stamp.
 2 - Enables Postfix Date Stamp.
