IDS Base Station Receiver 400 700-179-02B Issued January 2009 54
2 2.3 KHz handshake
3 1.4 KHz handshake
4 – SIA
4.7.2
4.7.24.7.2
4.7.2 Handshake
Handshake Handshake
Handshake D
DD
Durat
uraturat
uration
ion ion
ion M5x2
M5x2M5x2
M5x2
Some control panels have difficulty in understanding the receiver’s handshake tones on noisy phone
lines. The option provides a possible solution for this problem by providing longer constant tones.
Default : 20 (1 second tone length)
Increments of : 50ms
Max number : 99 (4.95 seconds)
4.7.3
4.7.34.7.3
4.7.3
Delay between H
Delay between HDelay between H
Delay between Handshakes
andshakes andshakes
andshakes M5x3
M5x3M5x3
M5x3
The line card default wait period for signals from the control panels is 4 seconds before sending the next
handshake that is if no acknowledge signal is received. In certain applications, an alarm panel may not
wait long enough to receive their own handshake, especially if the handshake is programmed as the third
or fourth handshake. This may be corrected by changing the time the IDS Base Station Receiver waits for
the alarm panel to acknowledge the handshake.
Default : 100 (2 seconds)
Increments : 20ms
Max value : 255 (5.1 seconds)
4.7.4
4.7.44.7.4
4.7.4
Max O
Max OMax O
Max Online
nline nline
nline T
TT
Time
ime ime
ime M5x4
M5x4M5x4
M5x4
This option determines how long the line card stays online for, before hanging up. This prevents runaway
panels from holding onto the line.
Default : 0 (feature disabled)
Increments : 1 minute
Max value : 99 (99 minutes)
4.7.5
4.7.54.7.5
4.7.5 Rings to
Rings to Rings to
Rings to A
AA
Answer
nswer nswer
nswer L
LL
Line
ine ine
ine M5x5
M5x5M5x5
M5x5
Determines the number of rings the line cards waits for before answering the line.
NOTE:
When using CALLER ID feature, the number of rings must not be less than two (2).
Default : 2 rings
Max value : 29
4.7.6
4.7.64.7.6
4.7.6
First Handshake D
First Handshake DFirst Handshake D
First Handshake Delay
elay elay
elay M5x6
M5x6M5x6
M5x6
This option changes the delay before sending the first handshake after taking the line.
Default : 2 seconds
Increments : 1 second
Max value : 19 (19 seconds)
