IDS 400 User Manual

IDS Base Station Receiver 400 700-179-02B Issued January 2009 51
4.6.14
4.6.144.6.14
4.6.14 Supervisory Poll (Heart B
Supervisory Poll (Heart BSupervisory Poll (Heart B
Supervisory Poll (Heart Beat) Signal Protoc
eat) Signal Protoceat) Signal Protoc
eat) Signal Protocol [1]
ol [1]ol [1]
ol [1]
PRRLsssssssssss@ssss[DC4] - Where
 P 1 - Protocol Identifier Number
 RR - Receiver number
 L 0 - System number
 s - Space character
 @ - Supervisory Signal
 [DC4] - Terminator, 14 hex (^T), acknowledge with (^F)
This signal is used to supervise the serial communication between the receiver and the computer. It is
sent to the computer every 30 seconds if no event data is available. The computer should acknowledge
this signal with an [ACK].
4.6.15
4.6.154.6.15
4.6.15 Status Report Messages [1]
Status Report Messages [1]Status Report Messages [1]
Status Report Messages [1]
The IDS Base Station Receiver will send the following messages to Sout Port to report internal status
conditions and will use the account code “0000” to indicate that it is reporting an internal condition.
The line number will be set to “0”.
PRRLssssAAAAAAsXGYYY[DC4] Where:
 P 1 - Protocol Identifier Number
 RR - Receiver number
 L 0 - System number
 s - Space character
 AAAAAA - Account code, usually 4 digits with 2 leading spaces [...0000]
 X - Event code. See Type
TypeType
Type in Table 19: Status Report Codes below
 G - O/C by area number (1-F), or space
 YYY - See Code
CodeCode
Code in Table 19: Status Report Codes below
 [DC4] - Terminator, 14 hex (^T), acknowledge with (^F)
Table 19: Status Report Codes
Acc
AccAcc
Acc AAAA
AAAAAAAA
AAAA Type
TypeType
Type X
XX
X Code
CodeCode
Code YYY
YYYYYY
YYY Event
EventEvent
Event
0000 A 01 Printer Error
0000 R 01 Printer Restoral
0000 A 03 Low Battery
0000 R 03 Battery Restoral
0000 A 05 Sout Port Absent
0000 R 05 Sout Port Restoral
0000 A 10 ERROR: Faulty data received on LC
0000 A 15 AC Fail
0000 R 15 AC Restoral
0000 A 20 Line Loss
0000 R 30 Line Restoral
0000 A 40 Missed Call: No data received on LC
0000 A D0 Power Failed
0000 R D0 Power up
0000 A F1...F4 Line Card Absent
0000 R F1...F4 Line Card Restoral
