IDS 400 User Manual

IDS Base Station Receiver 400 700-179-02B Issued January 2009 55
4.7.7
4.7.74.7.7
4.7.7 Line C
Line CLine C
Line Card
ard ard
ard O
OO
Options
ptions ptions
ptions M5x7
M5x7M5x7
M5x7
This options sets up various line card parameters. Options can only be “1” or “0”
Bit 1 2 3
Value 1 0 1
Table 20: Line Card Option Bits
Bit Function
1 Telephone line monitoring
0 – Disabled
1 - Enabled (default)
2 Sescoa superfast decoding
0 – Disabled (default)
1 – Enabled
3 Caller ID
0- Disabled
1 -Enabled (default)
NOTE:
1. See when using Sescoa Superfast
2. For “Caller ID” to function this facility must be enabled by the telephone line service provider
5.
5.5.
5. Appendix A
Appendix AAppendix A
Appendix A
5.1
5.15.1
5.1 Technical Notes
Technical NotesTechnical Notes
Technical Notes
The following is technical information gained from technical support and user input while operating and
installing the IDS BSR and IDS BSR400.
5.1.1
5.1.15.1.1
5.1.1 Sescoa Super
Sescoa SuperSescoa Super
Sescoa Superf
ff
fast
astast
ast
When using the Sescoa superfast format the following must be taken into account:
 Sescoa superfast format is 3x3 + Check Sum (total of 7 digits)
 Sescoa superfast account is a three digit code to the base 15, and is thus limited to a maximum
number of 3374.
 When the Sescoa superfast format is enabled, 4 by 2 plus parity formats will be identified as a
Sescoa and will not display the correct account code.
 If it is necessary to receive Sescoa superfast (SSF) and 4 by 2 + Check Sum formats disable the
SSF decoding and change the SSF account code, in the monitoring program, to the coded
format and make sure that the m.s.d. of all the event codes sent by the alarm panel set to SSF is
an “A”, e.g. the coded account code 1234 = 574 + the m.s.d. of the event code “A” which will
be seen by the IDS BSR400 as part of the account code and will be converted to a “0”, the result
is account code 5740.
 The coding of SSF account code is as follows:
• The range of a digit to the base 15 is [0...E]
• The value “0” is replace by the digit “F”
• The SSF account code [0000...3374] when coded will be in the range [FFF...EEE], e.g. 0001
= FF1, and the range when used as describe above will be [FFF0...EEE0]
