IDS 400

IDS Base Station Receiver 400 700-179-02B Issued January 2009 46
4.6.5
4.6.54.6.5
4.6.5 Enable Year Output
Enable Year Output Enable Year Output
Enable Year Output M414
M414M414
M414
The Year Output shall be enabled or disabled by entering [1] or [0] into the Enable Year Output setting.
 0 – Disables Year Output
 1 - Enables Year Output
4.6.6
4.6.64.6.6
4.6.6 Enable CALL ID
Enable CALL ID Enable CALL ID
Enable CALL ID M415
M415M415
M415
The Call ID shall be enabled or disabled by entering [1] or [0] into the Enable Year Output setting.
 0 – Disables CALL ID Output
 1 - Enables CALL ID Output
4.6.7
4.6.74.6.7
4.6.7 Format Event Code
Format Event Code Format Event Code
Format Event Code M416
M416M416
M416 M417
M417M417
M417 M418
M418M418
M418
The “Event Code Identifier” character “X”, see 4.6.13 Basic Signal Protocol, is selected by the control
program from Table 14, Table 15 and Table 16 which may be setup as shown in Table 17: Event Codes
Identifiers as an example of user defined “Event Code Identifier” characters. This option enables the user
to assign any identification character to the different received 4x1/2/3 formats in Table 14, Table 15 and
Table 16 below. During the serial output sequence, the entered event code identification characters are
selected from the format tables according to the value of the most significant digit of the received event
code and placed in the “X” position in the serial output sequence.
