IDS 400 User Manual

IDS Base Station Receiver 400 700-179-02B Issued January 2009 16
nc
1
ABC
2
DEF
3
5
55
5
GHI
4
JKL
5
MNO
6
6
66
6
PQRS
7
TUV
8
WXYZ
9
CANCEL
ENTER
*
SPACE
0
Cancel Alpha
#
SHIFT
3.2.1
3.2.13.2.1
3.2.1 Navigating and Editing
Navigating and EditingNavigating and Editing
Navigating and Editing
The numeric keypad doubles as an alphanumeric character entry device when used in conjunction with
the SHIFT key, see explanation below. The * key is used as an “enter” key. The # key is used
for direct access to menu items. The 5 or 6 keys are used to scroll through the event log, or
during an edit session to move the cursor left and right or in the roll mode to enter alpha numeric
characters. The CANCEL key is used to exit viewing events or the program mode or cancelling entered
data. The SHIFT and CLEAR keys are used in the alpha character entry mode.
3.2.1.1
3.2.1.13.2.1.1
3.2.1.1 Numeric Character Entry
Numeric Character EntryNumeric Character Entry
Numeric Character Entry
Press keys 0 to 9 to enter a numeric value and press * to select the data or CANCEL to
abandon the changes.
3.2.1.2
3.2.1.23.2.1.2
3.2.1.2 Alphan
AlphanAlphan
Alphanumeric Roll Entry
umeric Roll Entryumeric Roll Entry
umeric Roll Entry
Numeric and upper case alpha characters may be entered using the roll mode as follows.
When the cursor is at the entry point hold down the 5 or 6 to roll up or down through all the
alphanumeric characters until the desired character is reached then release the key. Wait a second for
the hold down time out then use the 5 or 6 key to move to the next cursor character to be
changed.
3.2.1.3
3.2.1.33.2.1.3
3.2.1.3 Alphabetical Character Entry
Alphabetical Character EntryAlphabetical Character Entry
Alphabetical Character Entry
Upper or lower case alphabetical character may be entered as follows.
The alphabetical character mode is selected when required by pressing the SHIFT key; this selects the
default upper case characters indicated by a “Blinking” cursor. To select lower case characters press the
SHIFT key a second time. To return to the numeric mode press the # key, the “Blinking” cursor will
switch off. Example:
To enter the “Y”
“Y”“Y”
“Y” character and then return to the numeric mode:
• Press the SHIFT
key then
• Press 9 , 9 , 9 (9 key three times) and
