IDS Base Station Receiver 400 700-179-02B Issued January 2009 8
User Interface
• Twenty (20) characters by four (4) lines Liquid Crystal Display (LCD) that displays the current
date, time and event status
• Sixteen-key keypad with alphanumeric, CANCEL , 5 , 6 and TEXT keys. The
[*], [0] and [#] keys function additionally as ENTER, SPACE and CLEAR ALPHA
• Log Event Viewer. View current and previous entries in the event log
• TROUBLE event log viewer
Program Mode for setting up IDS BSR400 and Line Card options.
• M000 – FIRMWARE VER. Control Card version display
• M100 – STATION SETUP.
• Base Station ID
• Master ID
• Date
• Time
• Load Defaults
• Clear Un-viewed
• Events
• Format Options
• M200 – PRINTER SETUP
• Enable Printer
• Plain Library
• Plain Library Setup
• M300 – ALARM EVENT
• SETUP Event Buzzer
• Event Relay
• Tagged Events
• CID Tagged Events
• SIA Tagged Events
• Wake-up Alarm
• M400 – SERIAL OUT SETUP
• Enable Serial Output
• Pre/Post Event Date
• Pre/Post Poll date
• Enable Year Output
• Enable Caller ID
• Format 4x1/2/3
• Serial Options
• Delay Between Sout
• Heart Beat Period
• Ack Wait Period
• M500 – LINE CARD 1...4 SETUP
• Handshake Order
• Handshake Duration
• Delay Between HS
• Max Online Time
• Ring to Answer Line
• First HS Delay
• Line Card Options
