AFL3-W19A-AL Panel PC

Page 84

6.2.1 Battery Connector (BAT1)

PIN NO. DESCRIPTION

1 VBATT

2 GND

Table 6-2: Battery Connector (BAT1) Pinouts

6.2.1 Chassis Intrusion Connector (CHASSIS1)

PIN NO. DESCRIPTION

1 +3.3VSB

2 Chassis open

Table 6-3: Chassis Intrusion Connector (CHASSIS1) Pinouts

6.2.2 Debug Connector (80PORT1)

PIN NO. DESCRIPTION PIN NO. DESCRIPTION

1 +5V (Reserved) 2 +3.3S

3 GND 4 INT_SERIRQ

5 LPC_AD3 6 LPC_AD2

7 LPC_AD1 8 LPC_AD0

9 LPC_FRAME_N 10 PLT_RST#

11 PLT_CLK 12 GND

Table 6-4: Debug Connector (80PORT1) Pinouts
