AFL3-W19A-AL Panel PC

Page 91

6.2.7 SATA Connector (SATA1)

PIN NO. DESCRIPTION PIN NO. DESCRIPTION

1 GND 11 +5V

2 GND 12 NC

3 GND 13 NC

4 GND 14 GND

5 GND 15 SATA_RXP0

6 GND 16 SATA_RXN0

7 +5V 17 GND

8 +5V 18 SATA_TXN0

9 +5V 19 SATA_TXP0

10 +5V 20 GND

Table 6-15: SATA Connector (SATA1) Pinouts

6.2.1 Speaker Connector (SPEAKER1)

PIN NO. DESCRIPTION

1 SPK-L+

2 SPK-L-

3 SPK-R-

4 SPK-R+

Table 6-16: Speaker Connector (SPEAKER1) Pinouts

6.2.2 SPI Flash Connector (JSPI1)

PIN NO. DESCRIPTION

1 +3.3V

2 SPI_CS

3 SPI_SO_SW

4 SPI_CLK_SW

5 SPI_SI_SW

6 GND

Table 6-17: SPI Flash Connector (JSPI1) Pinouts
