IEI Technology AFL3-W19A-AL User Manual

AFL3-W19A-AL Panel PC
Page 87
6.2.2 LVDS Connector (LVDS1)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GND 2 GND
3 A_Y0# 4 A_Y1#
5 A_Y0 6 A_Y1
7 GND 8 GND
9 A_Y2# 10 A_CK#
11 A_Y2 12 A_CK
13 GND 14 GND
15 A_Y3# 16 B_Y0#
17 A_Y3 18 B_Y0
19 GND 20 GND
21 B_Y1# 22 B_Y2#
23 B_Y1 24 B_Y2
25 GND 26 GND
27 B_CK# 28 B_Y3#
29 B_CK 30 B_Y3
31 GND 32 GND
33 GND 34 GND
35 LVDS_VCC 36 LVDS_VCC
37 LVDS_VCC 38 LVDS_VCC
39 LVDS_VCC 40 LVDS_VCC
Table 6-10: LVDS Connector (LVDS1) Pinouts
