IEI Technology AFL3-W19A-AL User Manual

AFL3-W19A-AL Panel PC
Page 70
4.4.2.2.2 MSATA1
Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc.
Chipset
MSATA1 [Enabled]
PCIe Speed [Auto]
Select PCI Express port
speed.
---------------------
 : Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc.
BIOS Menu 22: MSATA1
 MSATA1 [Enabled]
Use the MSATA1 option to enable or disable the mSATA slot.

Disabled
Disables the mSATA slot.

Enabled DEFAULT
Enables the mSATA slot.

Auto
Disables the
unused port automatically for the
most optimum power savings.
 PCIe Speed [Auto]
Use this option to select the support type of the PCI Express slot. The following options
are available:
 Auto Default
 Gen1
 Gen2
