AFL3-W19A-AL Panel PC

Page 19

Step 2: Lift the plastic back cover off the AFL3-W19A-AL.

Step 3: Remove the 15 retention screws from the internal aluminum cover.

See Figure 3-2.

Figure 3-2: Aluminum Cover Retention Screws

Step 4: Lift the aluminum cover off the AFL3-W19A-AL.

3.5 mSATA Module Installation

To install a full-size mSATA module into the AFL3-W19A-AL, please follow the steps

below:

Step 1: Remove the plastic back cover and the internal aluminum cover. See

Section 3.4 above.

Step 2: Locate the mSATA module slot. Remove the preinstalled retention screw on the

screw pillar as shown in Figure 3-3.
