1.7 System Specifications
The technical specifications for the AFL3-W19A-AL systems are listed in Table 1-2.
Specification AFL3-W19A-AL
LCD Size
18.5" (16:9)
Max. Resolution
1366 (W) x 768 (H)
Brightness (cd/m
2
)
250
Contrast Ratio
1000:1
LCD Color
262K
Pixel Pitch (H x V) (mm)
0.240 x 0.240
Viewing Angle (H-V)
170° / 160°
Backlight MTBF
30,000 hrs
Backlight
LED
Touchscreen
Projected capacitive type with anti-UV and anti-glare
coating, USB interface
Touch Controller
EETI EXC 3188
CPU (SoC)
Intel
®
Celeron
®
processor J3455 (quad-core, 2M cache,
1.5 GHz up to 2.30 GHz, TDP 10W)
Memory
One 204-pin 1600/1333 MHz single-channel DDR3L
SO-DIMM slot preinstalled with 4 GB SDRAM
(system max. 8 GB)
Ethernet
Two Intel
®
I211 PCIe GbE controllers
Storage
One full-size PCIe Mini slot supports mSATA module
One 2.5" SATA 3Gb/s HDD bay
Audio
Realtek ALC892 HD Audio codec
