Internal Speaker
Two 3 W
Camera
2-megapixel with low light function and digital
microphone
Wireless & Bluetooth
One M.2 2230 module supports 802.11a/b/g/n/ac
WLAN + Bluetooth v4.0
RFID Reader
Mifare 13.56 MHz card reader (optional)
Card Reader
Magnetic stripe card reader (optional)
OSD Function
Controlled by OSD software
Construction Material
PC+ABS plastic
Thermal Design
Fanless
VESA Mount
100 mm x 100 mm
Mounting
Panel, wall, stand or arm mounting
Front Panel Color
Black C
Net/Gross Weight
6.3 kg / 9 kg
Dimensions (W x H x D) (mm)
470 x 280 x 60
Operating Temperature
-15ºC ~ 50ºC (with air flow)
Storage Temperature
-20ºC ~ 60ºC
Humidity
10% ~ 95% (non-condensing)
Power Supply
60 W power adapter
Input:
100 V ~ 240 V AC, 50 Hz ~ 60 Hz
Output:
12 V DC, 5 A
Power Requirement
12 V ~ 34 V DC
Power Consumption
12 V @ 3.27 A (Intel® Celeron® processor J3455 with
4 GB 1600 MHz DDR3L memory)
