6.4.3 LVDS Panel Voltage Selection Jumper (J_VLVDS1)
Pin Description
Short 1-2 +3.3 V
Short 3-4 +5 V (Default)
Short 5-6 +12 V
Table 6-32: LVDS Voltage Selection Jumper (J_VLVDS1) Settings
6.4.4 LVDS Panel Resolution Selection Jumper (SW1)
* ON=0, OFF=1
SW1 (4-3-2-1) Description
0000 800x600 18bit (Default)
0001 1024x768 18bit
0010 1024x768 24bit
0011 1280x768 18bit
0100 1280x800 18bit
0101 1280x960 18bit
0110 1280x1024 48bit
0111 1366x768 18bit
1000 1366x768 24bit
1001 1440x960 48bit
1010 1400x1050 48bit
1011 1600x900 48bit
1100 1680x1050 48bit
1101 1600x1200 48bit
1110 1920x1080 48bit
1111 1920x1200 48bit
Table 6-33: LVDS Resolution Selection Jumper (SW1) Settings
