AFL3-W19A-AL Panel PC

Page 90

21 GND 22 PLTRST_N

23 PCIE_RXN(SATA_RX+) 24 +3.3V

25 PCIE_RXP-(SATA_RX-) 26 GND

27 GND 28 1.5V

29 GND 30 SMB_CLK

31 PCIE_TXN(SATA_TX-) 32 SMB_DATA

33 PCIE_TXP(SATA_TX+) 34 GND

35 GND 36 USB_DATA-

37 GND 38 USB_DATA+

39 +3.3V 40 GND

41 +3.3V 42 NC

43 NC 44 NC

45 NC 46 NC

47 NC 48 1.5V

49 NC 50 GND

51 MSATA_DET 52 +3.3V

Table 6-13: PCIe Mini Connector (MSATA1) Pinouts

6.2.6 Power LED Connector (PW_LED1)

PIN NO. DESCRIPTION

1 +5VS

2 GND

3 +5VA

Table 6-14: Power LED Connector (PW_LED1) Pinouts
