6.2.1 Debug Connector, EC (CN2)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 EC_EPP_STB# 2 EC_EPP_AFD#
3 EC_EPP_PD0 4 NC
5 EC_EPP_PD1 6 EC_EPP_INIT#
7 EC_EPP_PD2 8 EC_EPP_SLIN#
9 EC_EPP_PD3 10 GND
11 EC_EPP_PD4 12 NC
13 EC_EPP_PD5 14 EC_EPP_BUSY
15 EC_EPP_PD6 16 EC_EPP_KSI5
17 EC_EPP_PD7 18 EC_EPP_KSI4
Table 6-5: EC Debug Connector (CN2) Pinouts
6.2.2 Digital I/O Connector (DIO1)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GND 2 +5V
3 DOUT3 4 DOUT2
5 DOUT1 6 DOUT0
7 DIN3 8 DIN2
9 DIN1 10 DIN0
Table 6-6: Digital I/O Connector (DIO1) Pinouts
